1,本款机器切割功率大,面积达到1600mx3000mm,善于切割大型皮革,沙发布料等。
This machine cutting power, the area 1600 mx3000mm, is good at cutting large leather, sofa cloth, etc.
2,机器采用高品质三相步进电机,驱动器,运行更加稳定,精度更高。
Machine adopts high quality three-phase stepper motor, drive, run more stable and higher precision.
服装打样,大幅面裁断,皮革业,鞋业,装饰业,家具业,广告业,包装印刷业,模型业,工艺礼品业等。
布料,皮料,纸张,玩具面料,有机玻璃,橡胶,合成材料等。
Cloth, leather, paper, toy fabrics, organic glass, rubber, synthetic materials and so on.
激光类型(Laser type) | 封离式二氧化碳激光管 Seal type co2 laser tube |
激光功率(Laser power) | 80w,110w,130w可选/Optional |
有效工作面积(Effective work area) | 1300mmx2500mm |
工作台面(Table mode) | 固定蜂窝台面/履带 Fixed cellular mesa/track |
切割速度Cutting speed | 0-25000mm/min |
重复定位精度(Repeat positioning accuracy) | ±0.05mm |
工作电压(Working voltage) | AC220±10%50HZ/AC110V±10%60HZ |
总功率(The total power) | <2000W |
工作湿度(Working humidity) | 5%-95% |
工作温度(Working temperature) | 0-45℃ |
最小成型文字(Minimum forming words) | 中文3x3mm/English 1x1mm |
支持文件格式(Support the file format) | BMP,HPGL,PLT,DST,DXF,NC&AI ETC. |
分色切割(Color cutting) | 多达256层分色切割/reaches 256 color forcutting |
驱动电机(Drive motor) | 步进电机/Stepper |
冷却方式(Cooling mode) | 水冷及断电保护系统 Water and electricity protective system |
控制系统(Control system) | DSP控制系统 |
兼容软件(Compatible software) | DSP Controlling system Coreldraw/Auto CAD/Photoshop |
排烟装置(Exhaust device) | 强力中压风机及排烟管/Powerful medium pressure fan and exhaust pipe |
整机尺寸(The whole machine size) | 3230mmx1840mmx1100mm |
整机重量(The weight) | 600KG |
可选配件(Optional accessories) | 高级水冷机,旋转轴,空气过滤器/Advanced water-cooled machine, the axis of rotation, and the air filter |
